Specification

• Grinding length: 475 mm
• Grinding wheel speeds: 1500-2.700 U/min
• Number of clamping slots: 3-45
• Grinding slide feeds: 0-12 m/min
• Taper: ISO 40
• Grinding wheel diameter:
  -Used wheel: 180 mm
  -Unused wheel: 250 mm
• Max. grinding diameter:
  -Spiral flute: 230 mm
  -Straight flute: 250 mm
• Total power requirement: 6,4 kW
• Machine dimensions: 2060x1150x1700 mm
• Machine weight: 3,6 tons
