Specification

• Max. Gear Diameter 430 mm
• Max. Pinion Diameter 30-350 mm
• Center of gear spindle to nose of pinion spindle 125 – 260 mm
• Bore of work spindle taper 98 mm
• Axial cross angle 90°
• Axial shifting, vertical 0 – 1 mm
• Axial shifting, horizontal 0 – 1 mm
• Swinging motion, infinitely variable 0 – 4 mm
• Speeds of pinion spindle 600-1200 RPM
• Spindle drive 2.5 kW
• Total electrical load 5 kW-380V-50 Hz
• Nose of gear spindle 160-275mm
